GPS Data Logger: CANedge CAN Logger with GNSS/IMU [News]
news / 2023-05
The CANedge1 and CANedge2 GPS data logger variants combine 2 x CAN/LIN logging with an internal GNSS receiver and 3D IMU, adding 40+ GPS/IMU signals via sensor fusion. Plus: AGV predictive maintenance and Marple data analytics case studies.
CANedge incl. GNSS/IMU now available
We have now launched the CANedge1/CANedge2 with internal GNSS and 3D Inertial Measurement Unit (IMU).
In short: It's like a CANedge + CANmod.gps - but in one device!
Below are key features focused on the GNSS/IMU functionality (LinkedIn post):
1: GNSS/IMU signals
Add 40+ GNSS/IMU signals to your 2 x CAN/LIN data, incl. position, speed, trip distance, XYZ acceleration, roll/pitch/yaw and more
2: Compact
The CANedge incl. GNSS/IMU is 70%+ more compact vs. using a CANmod.gps, bracket and adapter
3: Low cost
Upgrading to a CANedge incl. GNSS/IMU is 60%+ lower cost vs. adding a CANmod.gps, bracket and adapter
4: Two free CAN channels
By internalizing the CANmod.gps functionality, you no longer "block" a CAN channel on the CANedge, granting you the full use of the 2 x CAN + 2 x LIN channels
5: GPS/IMU sensor fusion
The device offers 3X higher positioning accuracy via sensor fusion for automotives - even in GNSS hostile areas (parking lots, tunnels, mines)
6: High frequency
Output all GNSS/IMU messages at up to 5 Hz (vs. 1 Hz for most CANmod.gps messages)
7: Configurable
Fully customize which GNSS/IMU messages to record (and at what frequency) - including over-the-air for the CANedge2
8: DBC file
Free DBC file included for easy decoding of recorded GNSS/IMU messages to physical values
9: RTC sync via GNSS
Optionally sync the CANedge RTC via the internal high-precision GNSS time for continuous sub-second sync - ideal for fleets or for use cases where you need to log 3+ CAN buses via multiple CANedge units
10: Pro specs
The device uses the cutting-edge u-blox NEO-M9V module for enhanced precision and features
Predictive maintenance in 250+ AGVs
In this case study, one of our tier 1 automotive OEM users explain how they solve a challenge with battery thermal events for 250+ Automated Guided Vehicles (AGVs) across multiple warehouses by setting up predictive maintenance using the CANedge2.
"The CANedge2 enables plug & play integration with existing infrastructure - with consistent performance and quick support from CSS"
Marple: Data analytics visualization
Learn how the CANedge can easily be used with the Marple data analytics platform to visualize big data efficiently. The platform is designed for engineers and offers a lot of powerful functionality - check it out!
"The CANedge + Marple is a powerful combination for engineers looking to visualize and analyze their data with ease"
Status at CSS
The new CANedge incl. GNSS/IMU is a top 3 requests from our users - so we're really excited to release it and the initial feedback has been fantastic!
The focus now is on our #1 user request, which we hope to launch in the coming months. You can learn more on this in our next newsletter or by following us on LinkedIn.
This update was sent as part of our newsletter on 31 May 2023. You can also download it as a PDF.
